EMC/EMI

EMC/EMI covers all issues related to passing an emissions or susceptibility certification test. This includes topics related to the test specs, shielding, spectrum control by filtering or clock modulation, the use of ferrites, return path control, suppressing plane resonances, antenna design, sources of ingress and egress of radiation, and use of special materials.

ARTICLES

Maxim’s Compact Synchronous Buck Converters Provide Industry’s Lowest EMI Performance for Automotive Infotainment and ADAS Applications

Automotive designers can significantly lower EMI and increase efficiency with the pin-compatible MAX20073 and MAX20074 buck converters from Maxim Integrated Products, Inc. The compact converters, which offer one of the lowest EMI performance for low-voltage point-of-load applications, which are ideal for automotive infotainment and ADAS applications.


Read More

GAUSS INSTRUMENTS targets EMC testing with TDEMI ULTRA receiver series

The new benchmark for your EMC testing

The new EMI receiver TDEMI® ULTRA from GAUSS INSTRUMENTS provides industry-leading features, such as a 685 MHz real-time bandwidth, fast receiver scanning and multi GHz real-time scanning up to 40 GHz. It is a multi-purpose instrument for a wide range of applications and due to its compact design, a 12V supply, and a weight of less than 10 kg it is a fitting tool for field testing or on-board testing applications.


Read More

Würth Elektronik eiSos presents its 2018 Product Catalog

New & Innovative Passive Components

Over 1000 pages long, the new “Passive Components 2018” catalog is now available from Würth Elektronik eiSos. The manufacturer of electronic and electromechanical components presents its broad and significantly extended range in the categories of EMC Components, Power Magnetics and Signal & Communications – some of which are AEC-Q200 qualified. All the products listed in the catalog are available from stock, also as free samples.


Read More

Tektronix Accelerates EMI/EMC Compliance Testing

New All-in-One Solution Saves Engineers Time and Money Spent on Failed Compliance Tests

Tektronix, Inc., a worldwide provider of measurement solutions, today introduced EMCVu, a new all-in-one solution for EMI/EMC pre-compliance testing and troubleshooting. In today’s electronic design environment, about 50 percent of products fail electromagnetic compatibility (EMC) testing the first time.


Read More

Orbel Launches New Online Store

When it comes to EMI/RF Shielding, Orbel Corporation recognizes that engineers need the ability to access solutions in a timely manner. With that in mind, Orbel has launched a new, easy to use, online store with a unique selection of high quality products. Orbel’s store offers a wide range of EMI shielding products and custom board shield design capabilities, shipped directly from Orbel’s facility in the USA.


Read More

EVENTS

Trade shows EDI CON

EDI CON USA 2018

10/17/18 to 10/18/18
Santa Clara Convention Center
Santa Clara, CA
United States
Contact: Alyssa Connell

DOCUMENTS AND FILES

ANSYS-CPM model for Transient Analysis

Power Delivery Network(PDN) time domain noise analysis is an essential part for SI/PI/EMI analysis, SIwave can utilize CPM’s current PWL file as a current sink for transient analysis combed with C4 bump’s RLC parasitics to give more realistic and accurate noise value.
